Schneider Electric TeSys K Auxiliary Contact Block 4 NO Screw Clamps Terminals LA1KN40

Name: Schneider Electric TeSys K Auxiliary Contact Block 4 NO Screw Clamps Terminals LA1KN40
Brand: Schneider Electric
Price: 42.0 AED
Availability: InStock

AED 42.00

(Price Inclusive of VAT)

Marketplace

Delivery by 2-3 Days

Cash On Delivery

7 Days Returnable

15+ Years Of Trust

15+ Branches

Note: This product is a marketplace product, it's availability and delivery time will be inform you, when you place an order or you can check by contacting us through whatsapp or by call.

Brand:Schneider Electric

Collections:Electricals

Type:Auxiliary Contact Block

Description

Schneider Electric LA1KN40 TeSys K Auxiliary Contact Block for LC.K, LP.K, CA.K contractors with screw terminals (except LP4K, LP5K, CA4K). It offers 4 normally open contacts with a voltage rating of up to 10 A, 690 VAC and connection using screw terminal blocks. Front clip mounting ensures high reliability and durability. Multi-standard certification (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh).

Features

Front mounting with Screw clamp terminals
Instantaneous auxiliary contacts operation
Conventional Free Air Thermal Current 10 A
Minimum switching current of 5mA at 17V
Mechanical durability 30 million cycles

Specifications

Brand : Schneider Electric

Item Name : Auxiliary Contact Block

Model : LA1KN40

Color : Dark Grey

Conventional Free Air Thermal Current : 10 A (at 60 °C)

Rated Insulation Voltage : 690 V conforming to IEC 60947-5-1, 600 V conforming to UL, 600 V conforming to CSA

Ambient Air Temperature For Storage : -50-80 °C

Connections - Terminals : Screw Clamp Terminals 1 cable(s) 0.34-1.5 mm²flexible with cable end, screw clamp terminals 1 cable(s) 0.75-4 mm²flexible without cable end, screw clamp terminals 1 cable(s) 1.5-4 mm²rigid, screw clamp terminals 2 cable(s) 0.34-1.5 mm²flexible with cable end, screw clamp terminals 2 cable(s) 0.75-4 mm²flexible without cable end, screw clamp terminals 2 cable(s) 1.5-4 mm²rigid

Depth : 35 mm

Height : 30 mm

IP Degree Of Protection : IP2X conforming to IEC 60529

Irms Rated Making Capacity : 110 A at <= 690 V AC conforming to IEC 60947

Minimum Switching Current : 5 mA

Minimum Switching Voltage : 17 V

Non-overlap Time : 1.5 ms on de-energisation no overlap between NC and NO contact, 1.5 ms on energisation no overlap between NC and NO contact

Operating Altitude : 2000 m

Pole Contact Composition : 4 NO

Certifications : CB Scheme, CCC, UL, CSA, CE, UKCA

Protective Treatment : TC conforming to IEC 60068

Range Of Product : TeSys K, TeSys K control relay

Rated Operational Voltage Limits : 690 V AC 25...400 Hz

Tightening Torque : 1.3 N.m - with screwdriver Philips No 2, 1.3 N.m - with screwdriver pozidriv No 2

Width : 38 mm

Permissible Short-time Rating : 80 A 1 s, 60 A 500 ms, 110 A 100 ms

Auxiliary Contacts Operation : Instantaneous

Shielding Continuity Terminal : Without

Ambient Air Temperature For Operation : -25-50 °C

Standards : EN/IEC 60947-5-1, UL 60947-5-1, CSA C22.2 No 60947-5-1, GB/T 14048.5, JIS C8201-5-1

Environmental Characteristic : Normal Environment

Insulation Resistance : > 10 MOhm

Mounting Location : Front

Range Compatibility : TeSys K LC1K, TeSys K CA2K, TeSys K CA3K

Weight : 0.045 kg
