Schneider Electric TeSys K Auxiliary Contact Block 3NO + 1NC Front Mounting Screw Clamp Terminals LA1KN31

Name: Schneider Electric TeSys K Auxiliary Contact Block 3NO + 1NC Front Mounting Screw Clamp Terminals LA1KN31
Brand: Schneider Electric
Price: 42.0 AED
Availability: InStock

AED 42.00

(Price Inclusive of VAT)

Marketplace

Delivery by 2-3 Days

Cash On Delivery

7 Days Returnable

15+ Years Of Trust

15+ Branches

Note: This product is a marketplace product, it's availability and delivery time will be inform you, when you place an order or you can check by contacting us through whatsapp or by call.

Brand:Schneider Electric

Collections:Electricals

Type:Auxiliary Contact Block

Description

Schneider Electric LA1KN31 TeSys K Auxiliary Contact Block is one of the most minor contactor offerings in the market. Despite its compact size, the series offers solid performance and promises seamless integration into all applications. TeSys K is a series of compact contactors with various coil voltages and terminal connection options. The offer includes specific versions for railway applications (TeSys S207) and household appliances (TeSys S335).

Features

Control circuits available: AC, DC, low consumption, and silent coil
Applications: 2.2 kW, 4.5 kW, 5.5 kW in AC3 and AC4
Terminal connection types include:

Screw clamp
Faston connectors
spring clips
Pins for circuit boards
1 NO or 1 NC contact integrated

Available for 1-way motors, 2-way motors (reversing contactors), and pre-wired Star Delta version
Includes the entire range of control relays in the same design.
Possibility of expanding the number of auxiliary contacts using additional auxiliary contact blocks
Possibility of protecting the motor with additional LR2K thermal relays
Standards: IEC 60947, NF C 63-110, VDE 0660, BS 5424, UL, CSA, CE and CCC certificates.

Applications

Simple control systems
Interference sensitive areas, mains supply disturbed (silent contactor: LC7K)
Suitable for use with programmable control outputs (low consumption contactor)
Specific versions for railway applications (TeSys S207) and household appliances (TeSys S335).

Specifications

Brand : Schneider Electric

Item Name : Auxiliary Contact Block

Model : LA1KN31

Conventional Free Air Thermal Current : 10 A (at 60 °C)

Rated Insulation Voltage : 690 V conforming to IEC 60947-5-1, 600 V conforming to UL 60947-5-1, 600 V conforming to CSA C22.2 No 60947-5-1

Associated Fuse Rating : 10 A gG at <= 690 V conforming to IEC 60947

Ambient Air Temperature For Storage : -50-80 °C

Compatibility Code : LA1

Connections - Terminals : Screw clamp terminals 1 cable(s) 0.34-1.5 mm²flexible with cable end, screw clamp terminals 1 cable(s) 0.75-4 mm²flexible without cable end, screw clamp terminals 1 cable(s) 1.5-4 mm²rigid, screw clamp terminals 2 cable(s) 0.34-1.5 mm²flexible with cable end, screw clamp terminals 2 cable(s) 0.75-4 mm²flexible without cable end, screw clamp terminals 2 cable(s) 1.5-4 mm²rigid

Depth : 35 mm

Height : 30 mm

IP Degree Of Protection : IP20 conforming to IEC 60529

Irms Rated Making Capacity : 110 A at <= 690 V AC conforming to IEC 60947

Minimum Switching Current : 5 mA

Minimum Switching Voltage : 17 V

Non-overlap Time : 1.5 ms on de-energisation no overlap between NC and NO contact, 1.5 ms on energisation no overlap between NC and NO contact

Operating Altitude : 2000 m

Pole Contact Composition : 3 NO + 1 NC

Certifications : CB Scheme, CCC, UL, CSA, CE, UKCA

Protective Treatment : TH Conforming to IEC 60068

Range of Product : TeSys K, TeSys K control relay

Rated Operational Voltage Limits : 690 V AC 25...400 Hz

Tightening Torque : 1.3 N.m - with screwdriver Philips No 2, 1.3 N.m - with screwdriver pozidriv No 2

Width : 38 mm

Permissible Short-time Rating : 80 A 1 s, 60 A 500 ms, 110 A 100 ms

Auxiliary Contacts Operation : Instantaneous

Shielding Continuity Terminal : Without

Ambient Air Temperature For Operation : -25-50 °C

Standards : EN/IEC 60947-5-1, UL 60947-5-1, CSA C22.2 No 60947-5-1, GB/T 14048.5, JIS C8201-5-1

Environmental Characteristic : Normal Environment

Insulation Resistance : > 10 MOhm

Mounting Location : Front

Range Compatibility : TeSys K LC1K, TeSys K CA2K, TeSys K CA3K

Weight : 0.045 kg
