Schneider Electric Harmony XB5 Illuminated Buzzer Plastic Red Ø22 Continuous or Intermittent Tone 24V AC/DC XB5KS2B4

Schneider Electric Harmony XB5 Illuminated Buzzer Plastic Red Ø22 Continuous or Intermittent Tone 24V AC/DC XB5KS2B4

Name: Schneider Electric Harmony XB5 Illuminated Buzzer Plastic Red Ø22 Continuous or Intermittent Tone 24V AC/DC XB5KS2B4
Brand: Schneider Electric
Price: 237.3 AED
Availability: InStock

AED 237.30

(Price Inclusive of VAT)

Marketplace

Delivery by 2-3 Days

Cash On Delivery

7 Days Returnable

15+ Years Of Trust

15+ Branches

Note: This product is a marketplace product, it's availability and delivery time will be inform you, when you place an order or you can check by contacting us through whatsapp or by call.

Brand:Schneider Electric

Collections:Electricals

Type:Illuminated Buzzer

Description

Schneider Electric XB5KS2B4 Illuminated Buzzer is an accessory designed as an acoustic and signaling unit for individual mounting. It has a continuous or intermittent signal and its acoustic sound level is adjustable. Complies with EN/IEC60947-1, EN/IEC60947-4-1, EN/IEC60947-5-1, JIS C 4520, UL 508, CSA C22.2 No. 14. Thanks to protection class IP69, IP67 and IP66. It is also resistant to dust, shock, pressure washing, vibration and corrosion, making it ideal for use in harsh environments.

Features

An acoustic and signaling unit for individual mounting.
It has continuous or intermittent signal
Resistant to dust, shock, pressure washing, vibration and corrosion,

Specifications

Brand : Schneider Electric

Item Name : Annunciator

Model : XB5KS2B4

Rated Supply Voltage : 24 V, 24 V +/- 10 %

Bezel Material : Plastic

Cap/Operator Or Lens Colour : Red

Current Consumption : <= 58 mA

Depth : 55 mm

Height : 29 mm

Mounting Diameter : 22 mm

Overvoltage Category : Class II conforming to IEC 60536

Protective Treatment : TH

Certifications : UL listed, CSA, BV

Range Of Product : Harmony XB5

Signalling Type : Continuous or intermittent tone

Width : 29 mm

Supply Frequency : 50/60 Hz

NEMA Degree Of Protection : NEMA 4X, NEMA 13

Resistance To High Pressure Washer : 9000000 Pa at 80 °C, distance : 0.1 m

Supply Circuit Type : AC/DC

Ambient Air Temperature For Operation : -40-70 °C

Ambient Air Temperature For Storage : -40-70 °C

Standards : CSA C22.2 No 14, IEC 60947-5-1, EN 60947-5-4, JIS C8201-5-1, EN 60947-1, UL 508, IEC 60947-5-4, EN 60947-5-1, IEC 60947-1, JIS C8201-1, IEC 60529, EN 50102, IEC 50102

Noise Level : 90 dB 6.8 kHz 0.1 m +/- 10 %

Weight : 0.24 kg
