Schneider Electric EasyPact TVS Auxiliary Contact Block 2 NC Screw Clamp Terminals LAEN02 in Dubai, UAE
Schneider Electric EasyPact TVS Auxiliary Contact Block 2 NC Screw Clamp Terminals LAEN02 in Dubai, UAE

Schneider Electric EasyPact TVS Auxiliary Contact Block 2 NC Screw Clamp Terminals LAEN02

Regular price AED 16.80
(Price Inclusive of VAT)
Marketplace
Delivery by 2-3 Days
Cash On Delivery
7 Days Returnable
15+ Years Of Trust
15+ Branches
Quantity
Note: This product is a marketplace product, it's availability and delivery time will be inform you, when you place an order or you can check by contacting us through whatsapp or by call.
Brand:Schneider Electric
Collections:Electricals
Type:Auxiliary Contact Block
Description
Description
Description Specifications Reviews
  • Description
  • Specifications
  • Reviews

    Schneider Electric LAEN02 EasyPact TVS Auxiliary Contact Block has 2 normally closed quick contacts with a rating of up to 10A and 690V AC, which are connected using screw terminals. Thanks to its NC-certified mirror contacts, it can be used in safety applications. The simple clip-on mounting on the front ensures high reliability and durability. It is available worldwide, certified to multiple standards (IEC, UL, CSA, CCC, EAC, Marine) and Green Premium compliant (RoHs/Reach).

    Features
    • Used in electrical circuits and control systems
    • Instantaneous auxiliary contacts operation
    • Minimum switching current of 5mA at 17V
Specifications
Specifications
Specifications
  • Specifications

    Brand : Schneider Electric

    Item Name : Auxiliary Contact Block

    Model : LAEN02

    Color : Grey (RAL 7011)

    Conventional Free Air Thermal Current : 8 A (at 60 °C)

    Rated Insulation Voltage : 690 V - for control circuit conforming to IEC 60947-5-1

    Ambient Air Temperature For Storage : -60-80 °C

    Connections - Terminals : Control Circuit: screw clamp terminals 1 1-1 mm² - external diameter: 6 mm - cable stiffness: solid or flexible with cable end, control circuit: screw clamp terminals 1 1-1 mm² - external diameter: 6 mm - cable stiffness: solid or flexible without cable end, control circuit: screw clamp terminals 2 2.5-2.5 mm² - external diameter: 6 mm - cable stiffness: solid or flexible with cable end, control circuit: screw clamp terminals 2 2.5-2.5 mm² - external diameter: 6 mm - cable stiffness: solid or flexible without cable end

    Device Application : Signalling

    IP Degree Of Protection : IP20 conforming to IEC 60529

    Irms Rated Making Capacity : 140 A AC conforming to IEC 60947-5-1

    Mechanical Durability : 10 Mcycles

    Minimum Switching Current : 5 mA

    Minimum Switching Voltage : 17 V

    Non-overlap Time : 1.5 ms on energisation no overlap between NC and NO contact, 1.5 ms on de-energisation no overlap between NC and NO contact

    Operating Altitude : 3000 m without derating

    Pole Contact Composition : 2 NC

    Certifications : GOST

    Protective Treatment : TH conforming to IEC 60068

    Range : EasyPact

    Rated Operational Voltage Limits : <= 690 V

    Standards : IEC 60947-5-1

    Rated Short-time Withstand Current : 100 A - 1 s, 120 A - 500 ms, 140 A - 100 ms

    Switching Voltage : 17 V

    Auxiliary Contacts Operation : Instantaneous

    Ambient Air Temperature For Operation : -5-55 °C

    Environmental Characteristic : Standard Environment

    Insulation Resistance : > 10 MOhm

    Mounting Location : Front

    Range Compatibility : EasyPact (EasyPact TVS) LC1E

    Weight : 0.035 kg
