Oman Cables Single Core 10 sqmm PVC Wire 450/750V 91.44 meter Roll
(Price Includes VAT)
Order Now & Get it by 2 days
Sold by: Marketplace
Brand : Oman cables
Type : Electric Wire
Description
These wires are intended for use in the indoor application, distribution in conduits as well as in closed installation ducts, and for the internal wiring of appliances and apparatus. PVC compounds used in wires and cables asper BS 6004/BS EN 50525-2-31, are described in BS EN 50363-3 / BS 7655-4.2. Several grades of compounds are detailed in these standards for both insulation and sheathing requirements. PVC compounds are thermoplastic by nature and consequently are designed to operate within a prescribed temperature range. Grades of PVC can therefore be selected to suit particular environment temperatures, with the maximum conductor temperature for heat-resisting grade PVC being 90°C and the lowest operating temperature grade PVC below minus 30°C.
| Brand | Oman cables |
| Conductor Diameter | 10 SQMM |
| Color | Black, Red, Blue, Yellow, Green/Yellow |
| Insulation Material | PVC |
| Length | 91.44 M (100 yards) |
| Voltage Rating | 450/750V |
| Conductor | Annealed plain copper (single-strand solid) |
