Legrand Synergy White Double Pole Switch with Indicator 20A 250V 730012
AED 21.27
(Price Includes VAT)
Order Now & Get it by 2 - 3 Working Days
Sold by: Marketplace
Cash on
Delivery
7 Days
Returnable
15+
Years Of Trust
15+
Branches
During Ramadan, customer care and delivery services are available from 7:30 AM to 3:30 PM. You can place orders on the website anytime — we’ll process them within service hours.
Brand : Legrand
Type : Switch
Collections
Description
- Synergy - double pole switches - white - Front plates : white thermoset - Terminal screws captive and backed off ready for cabling - large angled terminal entries - Compact mechanism for maximized wiring space - Supplied with faceplate screw caps
- Double pole switches 20 A - 250 V - Conform to BS EN 60669 - 1 - For flush-mounting, back box to be min. 25 mm deep - Use cord outlet accessory box Cat. No 7 300 53 for external cord outlet - ASTA license - Nominal plate dimensions : 86 x 86 mm - DP switch with red LED power indicator - LED invisible until activated
| Brand | Legrand |
| Model | Synergy 730012 |
| Wiring system | 2-pole switch |
| Method of operation | Rocker/button |
| Push button switch | No |
| Assembly arrangement | Basic element with full cover plate |
| Number of rockers | 1 |
| Mounting method | Flush-mounted |
| Type of fastening | Screw mounting |
| With mounting plate | No |
| Material | Plastic |
| Material quality | Duroplast |
| Halogen free | Yes |
| Surface finishing | Glossy |
| Color | White |
| RAL-number (similar) | 9003 |
| Color of switch operator | White |
| Label space/information surface | No |
| Lighting | Yes |
| Function lighting | Illuminated (on) |
| Type of lighting | LED not exchangeable |
| Suitable for degree of protection (IP) | IP2X |
| degree of impact strength (IK) | IK01 |
| Nominal voltage | 250 V |
| Rated current | 20 A |
| Switching current for fluorescent lamps | 20 AX |
| Device width | 86 mm |
| Device height | 86 mm |
| Device depth | 33.5 mm |
| Built-in depth | 22 mm |
| Min. depth of built-in installation box | 30 mm |
| Operating / setting temperature | -5 - 40 °C |
| Storage temperature | -5 - 40 °C |
| Voltage type | AC |
| Frequency | 50 - 60 Hz |
| Cable section | 6-6 mm² |
