Legrand Mallia Senses Single RJ45 CAT6 UTP Socket Outlet 281162
(Price Includes VAT)
Due to current global supply and market conditions, product prices may occasionally change. If there is any change in the price of items in your order, our customer support team will reach out to you for confirmation before proceeding further. We sincerely appreciate your understanding and thank you for your continued support.
Order Now & Get it by 2 - 3 Working Days
Sold by: Marketplace
Brand : Legrand
Type : Data Socket
Description
The Legrand Mallia Senses RJ45 Cat 6 UTP Socket Outlet delivers high-speed data transfer up to 1 Gbps, allowing you to download a 1GB file in just 8 seconds. Designed for both residential and commercial use, it supports high-capacity Power over Ethernet (PoE) applications, transmitting data and power over twisted pair Ethernet cabling. This complete unit, sold under one catalog number, features TIA 568A/B color-coded contacts for standard wiring and a toolless connector with integrated crimping for fast, secure installation. Ideal for IP and analog phones, streaming, downloads, and online gaming, it ensures low latency and consistent performance. With a modern, slim design, a robust support frame, and a quick plate clipping system, it's built for easy installation and perfect integration into any contemporary space. Recommended for indoor use only.
| Brand | Legrand |
| Model | Mallia Senses |
| Surface mounting | No |
| Flush-mounted installation | Yes |
| Type of fastening | Engage (snap) |
| Assembly arrangement | Basic element with full cover plate |
| Type of connector | RJ45 8(4) |
| Category | 6 |
| Colour | Matt White, Matt Black, Dark Silver, Dark Bronze, Champagne |
| RAL-number | 9003 |
| Connection type | 110 |
| Shielded housing | No |
| Separate earthing connection | No |
| With label space | No |
| Mounting method shielding connection | None |
| Outlet direction | Straight |
| With dust cover | Yes |
| With terminal resistor | No |
| Degree of protection (IP) | IP20 |
| Colour coding | Yes |
| Device width | 86 mm |
| Device height | 86 mm |
| Device depth | 36.3 mm |
| Number of modules (module system) | 1 |
| Built-in depth | 28.7 mm |
| Degree of impact strength (IK) | IK04 |
| Operating / setting temperature | -5 to 50 °C |
| Storage temperature | -10 to 70 °C |
| Terminal marking indication | Yes |
| Halogen free | Yes |
| Antimicrobial treatment | No |
| Mounting method | Flush-mounted |
| Horizontal fixing center distance | 60.3–60.3 mm |
