Legrand Mallia Senses 2 Gang 2 Way Switch 16AX 281003
(Price Includes VAT)
Order Now & Get it by 2 days
Sold by: Marketplace
Brand : Legrand
Type : Switch
Description
The Mallia Senses 2 Gang 2 Way Switch 16AX, 250V is a reliable and elegantly designed switching solution, supplied as a complete set under a single catalog number. Engineered for indoor use, it features screw-type terminals with clearly marked connections for secure and straightforward wiring. The quick and easy plate-rocker clipping system ensures fast installation, while the dual switch configuration offers practical 2-point lighting control on one sleek plate. With smooth tactile motion and audible feedback, it delivers a satisfying user experience. Built with a robust support frame and a modern, slim profile, this switch is ideal for seamless integration into contemporary interior settings.
Brand | Legrand |
Model | Mallia Senses |
Wiring system | switch 1-pole |
Method of operation | Rocker lever |
Assembly arrangement | Basic element with full cover plate |
Push button switch | No |
Number of rockers | 2 |
Mounting method | Flush-mounted |
Type of fastening | Screw mounting |
With mounting plate | Yes |
Material | Plastic |
Material quality | Thermoplastic |
Halogen free | Yes |
Antimicrobial treatment | No |
Surface protection | Lacquered |
Surface finishing | Matt |
Colour | Matt White, Matt Black, Dark Silver, Dark Bronze, Champagne |
Lighting | No |
Suitable for degree of protection (IP) | IP20 |
Degree of impact strength (IK) | IK04 |
Nominal voltage | 250 V |
Rated current | 16 A |
Switching current for fluorescent lamps | 16 AX |
Monitoring contact | No |
Connection type | Screwed terminal |
Heating switch | No |
Washing machine switch | No |
Device width | 86 mm |
Device height | 86 mm |
Device depth | 36.8 mm |
Built-in depth | 24.9 mm |
Min. depth of built-in installation box | 35 mm |
Compatible with Apple HomeKit | No |
Compatible with Google Assistant | No |
Compatible with Amazon Alexa | No |
IFTTT support available | No |
Operating / setting temperature | -5 to 50 °C |
Storage temperature | -10 to 70 °C |
Voltage type | AC |
Frequency | 50-60 Hz |
Mandatory neutral | No |
Terminal marking indication | Yes |
Terminals capacity | 1-4 mm² |
Cable nature for connection | Flexible or rigid |
Cable section | 1-4 mm² |
