Legrand Mallia Senses 1 Gang 5 to 300 Watts Incandescent or 5 to 75 Watts LED Dimmer 100/230 volts 50/60Hz 281086
(Price Includes VAT)
Order Now & Get it by 2 days
Sold by: Marketplace
Brand : Legrand
Type : Dimmer Switch
Description
The Legrand Mallia Senses dimmer (5–300W incandescent and 5–75W LED, 100–240V, 50/60Hz) is a complete unit offered under a single catalog number, combining performance and sleek design. It features screw-type terminals for secure and enhanced contact, with clearly marked terminals for easy and accurate installation. Designed for indoor use, this dimmer can be retrofitted into existing lighting points and allows dimming of compatible loads from 10% to 100%. Its rotary control offers smooth operation, while the robust support frame ensures durability. With a slim, modern profile, it integrates perfectly with the overall Mallia Senses aesthetic, making it ideal for contemporary interior settings.
| Brand | Legrand |
| Model | Mallia Senses |
| Assembly arrangement | Basic element with adapter plate |
| Method of operation | Turn/push button |
| App control via Bluetooth | No |
| Dimming phase cut-on (leading edge) | Yes |
| Dimming phase cut-off (trailing edge) | Yes |
| Serial dimmer | Yes |
| Type of load | Resistive load |
| Substation input | No |
| Light value memory | Yes |
| Applicable with button | No |
| Applicable with movement sensor | No |
| Applicable with presence indicator | No |
| Applicable with time switch/timer | No |
| Applicable with transmission button | No |
| Applicable with infrared button | No |
| Mounting method | Flush-mounted |
| Type of fastening | Mounting with screw |
| Material | Plastic |
| Material quality | Thermoplastic |
| Halogen free | Yes |
| Surface protection | Untreated |
| Surface finishing | Matt |
| Colour | Matt White, Matt Black, Dark Silver, Dark Bronze, Champagne |
| Transparent | No |
| Suitable for degree of protection (IP) | IP20 |
| Degree of impact strength (IK) | IK04 |
| Nominal voltage | 240–240 V |
| Frequency | 50–60 Hz |
| Control voltage | 100–240 V |
| Nominal power resistive load | 5–300 W |
| Nominal power inductive load | 5–300 VA |
| Nominal power capacitive load | 5–75 VA |
| Max. switching power LED | 200 W |
| Connection type | Screwed terminal |
| Cable section | 1–4 mm² |
| Device width | 86 mm |
| Device height | 86 mm |
| Device depth | 57 mm |
| Min. depth of built-in installation box | 35 mm |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| IFTTT support available | No |
| Built-in depth | 33.9 mm |
| Operating / setting temperature | -5 to 35 °C |
| Storage temperature | -20 to 70 °C |
| Voltage type | AC |
| Mandatory neutral | No |
| Terminal marking indication | Yes |
| Stress test conformity (1000V) | Yes |
| Antimicrobial treatment | No |
| Terminals capacity | 1–4 mm² |
| Cable nature for connection | Flexible or rigid |
