Legrand Mallia Senses 1 Gang 13A Switched Fused Connection Unit with Cord Outlet 281141
(Price Includes VAT)
Due to current global supply and market conditions, product prices may occasionally change. If there is any change in the price of items in your order, our customer support team will reach out to you for confirmation before proceeding further. We sincerely appreciate your understanding and thank you for your continued support.
Order Now & Get it by 2 - 3 Working Days
Sold by: Marketplace
Brand : Legrand
Type : Cord Outlet
Description
The Legrand Mallia Senses 13A unit is a complete solution supplied under one catalog number, offering both functionality and refined design. It features screw-type terminals for secure and enhanced electrical contact, along with clearly marked terminals for quick and accurate installation. Built to comply with British Standards, it is suitable for heavy-duty use and includes safety features that prevent access to electrical contacts under the plate. The unit incorporates a fast plate clipping system and a robust support frame for dependable performance. With a sleek and slim profile, it maintains the unified look of the Mallia Senses range and is recommended for indoor use only.
available models:- 281141MW | 281141MB | 281141DS | 281141DB | 281141CH
| Brand | Legrand |
| Model | Mallia Senses |
| Connection type | Screw connection |
| Mounting method | Other |
| Type of current | AC |
| Rated current | 13 A |
| Rated voltage | 250 V |
| Dimensions glass fuse | 5x25 mm |
| Width | 86 mm |
| Height | 86 mm |
| Depth | 32 mm |
| Built-in depth | 25.1 mm |
| Degree of impact strength (IK) | IK04 |
| Degree of protection (IP) | IP20 |
| Operating / setting temperature | -5 to 50 °C |
| Storage temperature | -10 to 70 °C |
| Voltage type | AC |
| Nominal voltage | 250–250 V |
| Supply current | 13–13 A |
| Frequency | 50–60 Hz |
| Mandatory neutral | Yes |
| Terminal marking indication | Yes |
| Colour | Matt White, Matt Black, Dark Silver, Dark Bronze, Champagne |
| Halogen free | Yes |
| Antimicrobial treatment | No |
| Number of terminals | 5 |
| Terminals capacity | 1–4 mm² |
| Cable nature for connection | Flexible or rigid |
| Cable section | 1–4 mm² |
