Legrand Mallia Senses 1 Gang 13A Switched Fused Connection Unit with Cord Outlet 281141
(Price Includes VAT)
Order Now & Get it by 2 days
Sold by: Marketplace
Brand : Legrand
Type : Cord Outlet
Description
The Legrand Mallia Senses 13A unit is a complete solution supplied under one catalog number, offering both functionality and refined design. It features screw-type terminals for secure and enhanced electrical contact, along with clearly marked terminals for quick and accurate installation. Built to comply with British Standards, it is suitable for heavy-duty use and includes safety features that prevent access to electrical contacts under the plate. The unit incorporates a fast plate clipping system and a robust support frame for dependable performance. With a sleek and slim profile, it maintains the unified look of the Mallia Senses range and is recommended for indoor use only.
available models:- 281141MW | 281141MB | 281141DS | 281141DB | 281141CH
| Brand | Legrand |
| Model | Mallia Senses |
| Connection type | Screw connection |
| Mounting method | Other |
| Type of current | AC |
| Rated current | 13 A |
| Rated voltage | 250 V |
| Dimensions glass fuse | 5x25 mm |
| Width | 86 mm |
| Height | 86 mm |
| Depth | 32 mm |
| Built-in depth | 25.1 mm |
| Degree of impact strength (IK) | IK04 |
| Degree of protection (IP) | IP20 |
| Operating / setting temperature | -5 to 50 °C |
| Storage temperature | -10 to 70 °C |
| Voltage type | AC |
| Nominal voltage | 250–250 V |
| Supply current | 13–13 A |
| Frequency | 50–60 Hz |
| Mandatory neutral | Yes |
| Terminal marking indication | Yes |
| Colour | Matt White, Matt Black, Dark Silver, Dark Bronze, Champagne |
| Halogen free | Yes |
| Antimicrobial treatment | No |
| Number of terminals | 5 |
| Terminals capacity | 1–4 mm² |
| Cable nature for connection | Flexible or rigid |
| Cable section | 1–4 mm² |
