Legrand Galion 1 Gang 1 Way Switch 16AX 282400
(Price Includes VAT)
Due to current global supply and market conditions, product prices may occasionally change. If there is any change in the price of items in your order, our customer support team will reach out to you for confirmation before proceeding further. We sincerely appreciate your understanding and thank you for your continued support.
Order Now & Get it by 2 - 3 Working Days
Sold by: Marketplace
Brand : Legrand
Type : Switch Socket
Description
The Galion 1 Gang 1 Way Switch 16AX, 250V~ is a modern, ready-to-install lighting control solution, supplied complete under a single catalog number. Designed for indoor use, it features screw-type terminals for enhanced contact, clearly marked terminals for easy identification, and a strip length indicator to prevent wire wastage. Its honeycomb supporting frame ensures excellent stability and rigidity during installation. The sleek full-plate rocker with a silver barre adds a contemporary touch that matches the cover color, while included paint and dust protection keeps the product clean until use. Delivered with screws suitable for both flush- and surface-mounting boxes (plastic or metal), this switch offers reliable and practical single-point lighting control in a stylish design.
| Brand | Legrand |
| Model | Galion |
| Wiring system | Switch 1-pole |
| Method of operation | Rocker lever |
| Assembly arrangement | Basic element with full cover plate |
| Push button switch | No |
| Number of rockers | 1 |
| Mounting method | Flush-mounted |
| Type of fastening | Screw mounting |
| With mounting plate | Yes |
| Material | Plastic |
| Material quality | Thermoplastic |
| Halogen free | Yes |
| Antimicrobial treatment | No |
| Surface protection | Untreated |
| Surface finishing | Glossy |
| Colour | White, Black, Rose Gold, Champagne, Dark Silver |
| Lighting | No |
| Suitable for degree of protection (IP) | IP20 |
| Degree of impact strength (IK) | IK04 |
| Nominal voltage | 250 V |
| Rated current | 16 A |
| Connection type | Screwed terminal |
| Heating switch | No |
| Washing machine switch | No |
| Device width | 86 mm |
| Device height | 88 mm |
| Device depth | 38.4 mm |
| Built-in depth | 24 mm |
| Min. depth of built-in installation box | 30 mm |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| IFTTT support available | No |
| Operating / setting temperature | -5 to 50 °C |
| Storage temperature | -10 to 70 °C |
| Voltage type | AC |
| Frequency | 50-60 Hz |
| Mandatory neutral | No |
| Terminal marking indication | Yes |
| Terminals capacity | 1–4 mm² |
| Cable nature for connection | Flexible or rigid |
| Cable section | 1–4 mm² |
