Gazelle Industrial Thermal Camera 160 X 120 Pixels G9701
(Price Includes VAT)
Due to current global supply and market conditions, product prices may occasionally change. If there is any change in the price of items in your order, our customer support team will reach out to you for confirmation before proceeding further. We sincerely appreciate your understanding and thank you for your continued support.
Sold by: Marketplace
Brand : Gazelle
Type : Thermal Camera
Description
Gazelle G9701 Industrial Thermal Camera is specially designed for temperature measurement in substations. The 3.5-inch touch screen displays the optical and thermal view image in image, merging both channels. Helps you quickly find the fault based on the accurate temperature measurement of high temperature targets in the environment.
Features
- The device detects the real-time temperature, and displays it on the screen.
- Equipped with built-in memory module to store recorded videos, captured snapshots, and important data.
- The device can display a fusion of thermal view and optical view.
- The device supports multiple palettes, and you can set the palette mode according to the alarm function.
- Long-distance laser light supplement to point the thermography target.
| Brand | Gazelle |
| Type | Industrial Thermal Camera |
| Model | G9701 |
| Color | Black |
| Temperature Range | -20 to 550°C |
| IR Resolution | 160x120 pixels |
| Image Sensor | Uncooled Focal Plane Arrays |
| Pixel Pitch | 17µm |
| Field of View | 25°x18.7° |
| Focal Length | 6.2mm |
| Spatial Resolution (IFOV) | 2.74mrad |
| Aperture | F1.1 |
| Image Frequency | 25Hz |
