ABB Installation Contactor 1SAE341111M0630 40A 3P ESB40-30N-06
(Price Includes VAT)
Due to current global supply and market conditions, product prices may occasionally change. If there is any change in the price of items in your order, our customer support team will reach out to you for confirmation before proceeding further. We sincerely appreciate your understanding and thank you for your continued support.
Order Now & Get it by 2 - 3 Working Days
Sold by: Marketplace
Brand : ABB
Type : Control Circuit DC
Description
The ABB Installation Contactor 1SAE341111M0630 40A 3P ESB40-30N-06 is a high-performance solution for controlling single and three-phase loads up to 40 A in residential, commercial, and industrial applications. Designed for reliability and efficiency, it offers hum-free operation, low power consumption, and integrated overvoltage protection, with compliance to IEC, UL, CE, UKCA, and other international standards. This 3-pole contactor supports both AC and DC operation, delivers up to 27.7 kW rated power, and ensures long service life with up to 150,000 electrical cycles and 1,000,000 mechanical cycles. Compact in size (54 × 65 × 85 mm) and DIN rail mountable, it features IP20 protection, RoHS/REACH compliance, and ABB EcoSolutions certification, making it an ideal choice for lighting, HVAC, automation, and household installations.
| Brand | ABB |
| Model | ESB40-30N-06 |
| Product ID | 1SAE341111M0630 |
| Product Type | Control Circuit DC |
| Width | 54 mm |
| Height | 85 mm |
| Depth | 65 mm |
| Net Weight | 0.385 kg |
| Rated Current | 40 A |
| Number of Poles | 3P |
| Operational Voltage | 400 V AC / 220 V DC |
| Control Voltage | 230 V AC/DC |
| Rated Power | Up to 27.7 kW (400 V AC-1) |
| Protection Class | IP20 |
| Mounting | DIN Rail (TH35) |
| Standards | IEC/EN 60947-1, IEC/EN 60947-4-1, IEC/EN 61095, UL 60947 |
